product name	CL5030TSL6GH road sweeper
Maximum speed (km/h)	110	Maximum speed (km/h)	110
Remark:	Remarks: 1. Special devices: garbage cans, water tanks, scrubbing brushes and other devices to realize the function of road sweeping and cleaning; 2. ABS system controller model/manufacturer: APG3550500A/Zhejiang Asia Pacific Mechanical and Electrical Co., Ltd.; 3. Engine model/maximum net power: LJ4A15Q6/79Kw; 4. Cab is optional with the chassis; 5. Length/wheelbase correspondence (mm): 5010/2600, 5210/2800, 5410/3000; quality due to dimensional changes The change is within 1% and can be ignored.
Control switch:	Integrated superposition design, electro-hydraulic centralized control in the cab, convenient operation.
fan	It adopts high-power wear-resistant centrifugal maintenance-free fan with strong suction, low noise and simple maintenance. The impeller is welded with high-strength steel plate and has been corrected by static and dynamic balance. It has good aerodynamic performance, stable operation and high strength. And long service life, simple maintenance, reliable performance
Solenoid valve group	The core component of the vehicle hydraulic system controls the hydraulic drive of the entire vehicle and the two-way operation button, including a series of mechanical operations such as sweeping plate lifting, suction cup lifting, garbage bin lifting, rear door opening and closing, etc. The vehicle is equipped with a solenoid valve control box cover. Effectively prevent dust and garbage from entering the box.
Electromagnetic water pump	12V/24V, control the water spray bracket above the sweeping brush, effectively suppressing the secondary dust generated by the sweeping brush
cycloid motor	It can drive the sweep brush to rotate at high speed, has a long service life, is stable and reliable, and has a low failure rate!
Sweep	Use an inclined sweep brush to sweep the garbage in front of the suction cup. Under the negative pressure generated by the fan, the air flow will suck the garbage into the garbage bin for storage in a closed circuit.
suction cup	It adopts a fully floating suction nozzle that can automatically level with the road surface, which has good dust collection effect and long service life.

A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.

2. Q: Where is your factory located?

A: We are located in Suizhou City,Hubei Province,China

3.Q:How can i visit there?

A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.

4.Could you customize exactly according to my requirements?

A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.

5.Q: Do you provide certification that we need?

A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.

6.Q: what's your payment terms?

A:T/T& L/C are preferred.

7.Q:Do you arrange shipment for the vehicles?

A:Yes,we can arrange shippment based on trade terms.

8. Q:What service can I get from you?

A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.

9.Q:How is the packing?

A:All the packing comply with exporting standard.

10.Q:How long is the lead time?

A:20-25 working days.

For other questiones,we will reply you ASAP after receiving your consult!
