Rated capacity

13,000 liters

Tank Dimensions

5700× 2400 × 1600mm

Rated capacity

10,300 kg

curb weight

7505 kg

Sub-warehouse

The three warehouses are divided equally.

Tank form

Oval horizontal design, integrated with the   carriage

Tank material

SUS304-2B Food Grade

Liner thickness

δ3.0 mm

Outer layer thickness

δ1.0mm

Milk outlet diameter

∮51mm standard/non-standard

Insulating materials

70mm polyurethane spraying

+10mm rubber and plastic insulation cotton

Insulation performance

Polyurethane spraying foam is used, and the   thermal insulation performance does not exceed 2°C for   24 hours.

can

Single-layer butterfly head

3 mm thick

Cleaning method

CIP automatic cleaning, each compartment is   equipped with a cleaning ball to meet 360° cleaning   requirements.

car chassis

Isuzu chassis, 4700mm wheelbase , B6.2NS6B2 00   2 00 horsepower China VI engine, 8-speed transmission, 10.00R20 steel wire   tires, air brakes, with BS , air conditioning, and electric windows;

Comment

1. The milk unloading switch and cleaning   switch are made into a cluster structure, and each milk compartment is marked   with a number. Before the vehicle leaves the factory, the transport medium   and the announced volume are sprayed on the tank body according to the   announcement requirements.

2. Tank volume: 13000L ;

3. The rear control box uses a gas spring   lift-up opening mechanism and is equipped with an opening handle;

4. Each manhole cover and rear toolbox is   equipped with a lead seal device to facilitate management when loading and   unloading fresh milk from the milk truck;

5. Equipped with a movable ladder for   personnel to enter and exit the tank;

6. Divided into 3 equal compartments   [customizable], 2 expansion support plates, 3 ∮500mm   food-grade tank openings;

7. Each compartment has 2 automatic cleaning   balls, controlled by 3 valves with valve interfaces of ∮51   mm .
