Rated capacity

20,000 liters

Tank Dimensions

7300×2490× 1720mm

Rated capacity

15,000 kg

curb weight

9805 kg

Sub-warehouse

The three warehouses are divided equally.

Tank form

Oval horizontal design, integrated with the   carriage

Tank material

SUS304-2B Food Grade

Liner thickness

δ3.0 mm

Outer layer thickness

δ1.0mm

Milk outlet diameter

∮51mm standard/non-standard

Insulating materials

70mm polyurethane spraying

+10mm rubber and plastic insulation cotton

Insulation performance

Polyurethane spraying foam is used, and the   thermal insulation performance does not exceed 2°C for   24 hours.

can

Single-layer butterfly head

3 mm thick

Cleaning method

CIP automatic cleaning, each compartment is   equipped with a cleaning ball to meet 360° cleaning   requirements.

car chassis

Isuzu chassis, wheelbase 5700+1370 mm, 350   horsepower China VI engine, 8-speed gearbox, 295/80R22.5 tubeless tires, air   brakes, ABS , air conditioning, and power windows;

Comment

1. The milk dispensing and cleaning switches   are arranged in a cluster structure, and each milk compartment is labeled   with its number. Before the vehicle leaves the factory, the conveying medium   and the announced volume are sprayed on the tank body according to the   requirements of the announcement;

2. Tank volume: 20,000L ;

3. The rear control box uses a gas spring   lift-up opening mechanism and is equipped with an opening handle;

4. Each manhole cover and rear toolbox is   equipped with a lead seal device to facilitate management when loading and   unloading fresh milk from the milk truck;

5. Equipped with a movable ladder for   personnel to enter and exit the tank;

6. Divided into 3 equal compartments   [customizable], 2 expansion support plates, 3 ∮500mm   food-grade tank openings;

7. Each compartment has 2 automatic cleaning   balls, controlled by 3 valves with valve interfaces of ∮51   mm .
