Your products's number
| Basic Information | |
| Chassis model number: | Japanese brand - GIGA |
| Drive type: | 6X4 |
| Wheelbase: | 4350+1370mm / 4650+1370mm / 5100+1370mm /5700+1370mm |
| engine: | Japanese brand engine |
| Transmission: | FSAT |
| Vehicle length: | 10000mm / 10500mm /11000mm /11450mm |
| Vehicle width: | 2.55 meters |
| Vehicle height: | Based on actual height |
| Front track: | 2060mm |
| Rear track: | 1855mm |
| Maximum speed: | 89km/h |
| fuel tank capacity | 300L |
| Place of origin: | China |
| Tonnage class: | Heavy trucks |
| Energy type: | diesel fuel |
| Engine parameters | |
| Engine brand: | Japanese brands |
| Engine horsepower | 300HP / 380HP / 460HP |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Displacement: | 7.79L |
| Maximum output power: | 220kW / 279kW / 338kW |
| Transmission parameters | |
| Gearbox brand: | FSAT |
| Gear shifting method: | Manual transmission |
| Forward gear: | gears / 12 gears |
| Number of reverse gears: | 2nd gear |
| Cab parameters | |
| Driver's cab: | Japanese brand - GIGA |
| Passenger capacity: | 2 people |
| Driver's seat configuration: | Mechanical Seat |
| Chassis parameters | |
| Front axle allowable load: | 7000kg |
| Rear axle allowable load: | 10000kg / 13000Kg |
| Speed ratio: | |
| tire | |
| Tire specifications: | 295/80R22.5 / 315+385/80R22.5 |
| Number of tires: | 10+1 spare tires |
| Crane Information | |
| Crane Brands | Sany-Palfinger |
| Crane Model | SPS4000 |
| Maximum lifting mass | 16000kg |
| Maximum reach arm length | 19m |
| Number of hydraulic telescopic booms | 5articulated arm |
| Amplitude range | 0~76° |
| Rotation angle | endless |
| outrigger stride | 2338-7250mm |
| Product weight | 6000kg |
| Recommended hydraulic flow rate | 80-100L/min |
| Maximum working pressure | 32 MPa |
| Ambient oil temperature range | below zero25℃~40℃ |
| Hydraulic oil tank capacity | 300L |
| Operation method | Manual/Remote Control |
