| Truck Brands | HOWO |
| Chassis model: | 371 |
| Drive type: | 6X4 |
| engine: | WD615.47 engine |
| Vehicle length: | 9600/10000/10500/11000mm (actual length may vary) |
| Vehicle width: | 2350/2400/2450/2500mm (subject to actual length) |
| Vehicle height: | Based on actual height |
| wheelbase | 5200 + 1350 mm |
| Maximum speed: | 89km/h |
| Fuel tank capacity: | 300L |
| Energy type: | diesel fuel |
| beam structure | (8+5+8) *300mm |
| chassis suspension | Standard springs (10 in the front + 12 in the back) |
| Engine parameters | |
| Engine series | WD615 series |
| Engine model: | WD615.47 engine |
| Engine power | 273kW |
| Engine horsepower | 371 horsepower |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Displacement: | 10.518L |
| Emission standards: | European V |
| Maximum output power: | 273kW |
| Rated speed | 2200rpm |
| Maximum horsepower: | 371 horsepower |
| Maximum torque: | 1500 N.m |
| Maximum torque speed | 1100-1600rpm |
| Engine weight | 850kg |
| Transmission parameters | |
| Gearbox brand: | Sinotruk |
| Transmission model: | HW19712 |
| Gearbox Series | HW12 series |
| Number of gears | 10+2 |
| forward gear | 10 forward gears |
| Reverse gear | 2 reverse gears |
| Gear shifting method: | Manual transmission |
| Maximum output torque | 1900 N.m |
| Does it have a synchronizer? | yes |
| Transmission fluid capacity | 13L |
| Chassis parameters | |
| Driver's cab: | HW76 Single Sleeper Cab |
| Driver's seat direction | left |
| Passenger capacity: | 2 people |
| Driver's seat configuration: | Shock-absorbing seats |
| front axle | VGD95 self-adjusting boom front axle (drum type) |
| intake system | Highway version air intake system |
| Exhaust system | Standard exhaust system |
| Power Take-Off (PTO) | Cable-stayed PTO |
| Electrical system | NANO Electrical Systems |
| Reversing warning sound | beep notification tone |
| taillights | Seven-function halogen taillights |
| Window lift | Electric lift windows |
| Air conditioning settings: | Air conditioning |
| Sunshade | External sunshade |
| fuel tank capacity | 400L |
| Chassis parameters | |
| Front axle allowable load: | 7500kg |
| Rear axle allowable load: | 16000kg |
| tire | |
| Tire specifications: | 12.00R20 tires (18PR) |
| Number of tires: | 10+1 |
| Tire specifications (metric): | 12.00R20 |
| Crane Information | |
| Crane Brands | XuGong |
| Crane Model | GSQS250 |
| Number of hydraulic telescopic rods | 4 |
| Maximum lifting weight | 12000kg |
| Maximum hydraulic elongation | 14.8m |
| Maximum lifting height | 16.8m |
| Rotation angle | endless |
| Work pressure | 63+40Mpa |
| Hydraulic oil tank capacity | 270L |
| Crane self-weight | 4810kg |
| Forward leg stride | 2400-6000mm |
| Rear support leg span | 2300-3500mm |
| pallet information | |
| pallet length | 5600/ 5800/6000/6500/7000 (Special sizes can be customized) |
| pallet width | 2300 /2350 /2400 / 2450 /2500 (Custom sizes available) |
| pallet material | carbon steel patterned plate |
| pallet thickness | 3mm / 5mm |
| Beam spacing | 25-30cm / 30-35cm |
| Main bearing capacity | 18,000 kg - 25,000 kg |
