Your products's number
| Truck Brands | HOWO |
| Chassis model: | TX |
| Drive type: | 8X4 |
| engine: | WP8.350E61 |
| Vehicle length: | 9600/10000/10500/11000mm (actual length may vary) |
| Vehicle width: | 2350/2400/2450/2500mm (subject to actual length) |
| Vehicle height: | Based on actual height |
| wheelbase | 5200/5825 + 1350 mm |
| Maximum speed: | 89km/h |
| Fuel tank capacity: | 300L |
| Energy type: | diesel fuel |
| beam structure | (8+5+8) *300mm |
| chassis suspension | Standard springs (10 in the front + 12 in the back) |
| Engine parameters | |
| Engine series | WP8 series |
| Engine model: | WP8.350E61 |
| Engine power | 257kW |
| Engine horsepower | 350 horsepower |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Displacement: | 7.8L |
| Emission standards: | European VI |
| Maximum output power: | 257kW |
| Rated speed | 2100rpm |
| Maximum horsepower: | 350 horsepower |
| Maximum torque: | 2100 N.m |
| Maximum torque speed | 1200-1600rpm |
| Engine weight | 700kg |
| Transmission parameters | |
| Gearbox brand: | Sinotruk |
| Transmission model: | HW25712XSTL+HW70 Flange-type TPO |
| Gearbox Series | HW12 series |
| Number of gears | 12+2 |
| forward gear | 12 forward gears |
| Reverse gear | 2 reverse gears |
| Gear shifting method: | Manual transmission |
| Maximum output torque | 1700 N.m |
| Does it have a synchronizer? | yes |
| Transmission fluid capacity | 9.5L |
| Chassis parameters | |
| Driver's cab: | TX Single Sleeper Cab |
| Driver's seat direction | left |
| Passenger capacity: | 2 people |
| Driver's seat configuration: | Main airbag suspension seat |
| front axle | VGD95 self-adjusting boom front axle (drum type) |
| intake system | Engine intake air electric heating system |
| Exhaust system | U-shaped exhaust system |
| Power Take-Off (PTO) | Cable-stayed PTO |
| Electrical system | NANO Electrical Systems |
| Reversing warning sound | Optional buzzer sound |
| taillights | Seven-function halogen taillights |
| Window lift | Electric lift windows |
| rearview mirror | Electric heated rearview mirror |
| Air conditioning settings: | Air conditioning |
| Sunshade | External sunshade |
| fuel tank capacity | 300L |
| Chassis parameters | |
| Front axle allowable load: | 7500kg |
| Rear axle allowable load: | 13000kg |
| tire | |
| Tire specifications: | 11.00R20 tires (18PR) |
| Number of tires: | 12+1 |
| Tire specifications (metric): | 12.00R20 |
| Crane Information | |
| Crane Brands | Zoomlion |
| Crane Model | ZLT4000 |
| Number of hydraulic telescopic rods | 5 |
| Maximum lifting weight | 16000kg |
| Maximum hydraulic elongation | 22m |
| Maximum lifting height | 24m |
| Rotation angle | endless |
| Work pressure | 32Mpa |
| Hydraulic oil tank capacity | 270L |
| Crane self-weight | 6880kg |
| Forward leg stride | 2400-8600mm |
| Rear support leg span | 2300-3500mm |
| Pallet Information | |
| pallet length | 5600/ 5800/6000/6500/7000 (Special sizes can be customized) |
| pallet width | 2300 /2350 /2400 / 2450 /2500 (Custom sizes available) |
| pallet material | carbon steel patterned plate |
| pallet thickness | 3mm / 5mm |
| Beam spacing | 25-30cm / 30-35cm |
| Main bearing capacity | 18,000 kg - 25,000 kg |
| Ladder information | |
| Ladder width | 600mm / 700mm / 750mm |
| Ladder length | 2200mm / 2300mm / 2500mm |
| Linkage Method | Manual flipping/hydraulic flipping |
