Total mass :

7360kg

Rated   load quality :

1615kg

Curb weight :

5550kg

Chassis   model:

BJ1076VEJDA-51

Type:

4×2 , flat-head diesel vehicle

engine   model:

Q28-130C60

Engine maximum power :

96kW

Tail gas emissions:

Euro 3

Wheelbase:

3360mm

Cleaning part

Clean water tank volume:

2m³

Tank   thickness:

6mm

High pressure pump brand

Yifeng SK-9

Flow volume / pressure

267L/170Bar

High pressure hose inner diameter

15mm

High pressure hose length

100m

nozzle

Ceramic   nozzle four-piece set

Protection   System

Low water electronic alarm

absorb dirt

Sewage tank capacity:

4m 3

Sewage tank cross- sectional shape

round

Tank thickness

6mm

Vacuum   pump model:

Yifeng SK-9

Vacuum   pump flow rate :

1200m³/h

When the tank is full

≤5min

suction   lift

≥8m

Inlet / discharge valve port diameter

5H /   6H

Rear   tank door opening method

Hydraulic opening

Protection System

Four-level   protection system ( first -level   anti-overflow valve, cyclonic second - level   stop valve, anti-overflow cut-off   valve electronics

Anti-overflow alarm)

swivel boom

Can be moved forward   and backward        ,   up and   down , left and right for remote   control operation

sewage suction pipe

16m

Control system

Integrated electric   control box, manual / remote control, simple and convenient , low learning cost
