Total   mass:

8280 kg

Rated   load capacity:

2985 kg

Curb weight :

5100 kg

type:

4×2 flat-head diesel   truck

Engine   model:

4KK1N6HD

Maximum engine   power :

118 kilowatts

Exhaust emissions :

National VI

Wheelbase:

3365 mm

Cleaning   section

Clean water tank capacity:

3.0 cubic meters

Tank   thickness:

6 mm

High pressure pump   brands

Yifeng

Flow / Pressure

200   liters/150 bar

High-pressure hose   inner diameter

22 mm

High-pressure hose length

100m

nozzle

Ceramic nozzle four-piece set

Protection system

Low water level electronic alarm

Absorb dirt

part

Wastewater   tank capacity:

3.8 meters 3

cross-sectional shape of sewage tank

round

Tank thickness

6 mm

Vacuum   pump model:

Yifeng SK-15

Vacuum pump flow rate:

2000 cubic   meters/hour

When the water   tank is full

≤5 minutes

suction

≥18m

Intake /   exhaust valve diameter

5 hours / 6 hours

Rear hatch opening method

Hydraulic opening

Protection system

Four-level protection system ( Level 1 anti-overflow valve, Cyclone Level 2 shut-off valve , Anti-overflow shut-off valve electronic device)

Overflow   alarm)

Rotary arm

Move the device                                up, down   , left , and right to control it remotely.

sewage suction tube

16m

control system

Integrated electrical control box, manual / remote   control, simple and convenient , low learning curve.
