emulsified asphalt system

emulsified asphalt tank

l

2200

Maximum asphalt flow

l/min

270

Measurement method

/

Hall sensor/pump speed adjustment

Asphalt pump insulation method

/

Hot water insulation

water system

water tank

L

2200

maximum water flow

L/min

350

Measurement method

/

Flowmeter display/pump speed   adjustment/valve adjustment

stone system

Stone warehouse (full warehouse)

M ³

7.5

Conveyor belt bandwidth

mm

550

Stone conveying capacity

kg/min

2200

Adjustment method

/

Speed adjustment

Anti-clogging device

/

DC vibration motor

Stirring system

Stirring ability

Kg/min

1800-2200

Stirring form

/

Double shaft powerful mixing

paving box

Paving width

m

2.5--3.7

system

Width adjustment method

/

Hydraulic telescopic adjustment

Paving thickness

mm

3--15

Speed adjustment

/

Hydraulic adjustment

Auxiliary scraping device

/

Second scraping

Cleaning system

Cleaning method

High pressure cleaning

Control System

Microcomputer PLC

/

Chengliwei special controller

control method

/

Manual / Auto

Chassis

model

/

DFH1180EX8

Manufacturer

/

Dongfeng Commercial Vehicle Co., Ltd.

top speed

km/h

89

Drive type

/

4X2 driver

front/rear suspension

mm

1 430 /2640

Wheelbase

mm

5000

Approach / departure angle

°

21/10

minimum ground clearance

mm

460

Tire specifications

/

10.00R20 18PR

Engine horsepower

Cummins 230 HP

Emission Standards

/

Euro 3
