end     plate

QL1180EQFRY

Wheelbase

4700mm

engine

6HK1-TCG61

power

176kW

Drive type

Rear wheel drive

【 Tank    】

capacity:

Water 6000Kg, foam 2000Kg

[ Fire pump and piping system ]

fire pump brand

Shanghai Rongshen

Fire pump model

CB10/60 low   pressure fire pump

fire pump   pressure

1.0MPa

Fire pump   flow

 60L/s

Installation type

rear

Water diversion time

≤35s

Pump material

Wear-resistant and corrosion-resistant to   meet sealing requirements

Maximum vacuum degree

≥85kPa

Water   absorption depth

≥7m

Vacuum pump

Piston type , vacuum pumps   are preferably electric vacuum water diversion pumps of the same brand as   fire pumps.

【 Fire cannon 】

brand

west

model

PS20 type   fire monitor

range

Water ≥ 45 m

pressure

1.0MPa

Location

on top of the jug

control

It adopts manual control and has a locking   mechanism.

【 PTO 】

Type

Full power sandwich power take- off

cooling method

Forced water cooling

[ Equipment box and pump room ]

The   frame and skin are made of high-quality carbon steel; the internal equipment   rack is made of aluminum alloy profiles, and the interior panels are oxidized   aluminum plates

【 Electrical system 】

1. The top of the cab is equipped with a   long row of red luxury police lights.

2. The alarm power is 100W;

3. In order to ensure safe use, the entire   vehicle line is made of an integral wiring harness, and waterproof plugs are   used at the connections to ensure line safety during use.

4. The   roof of the vehicle is equipped with a fire scene lighting lamp ;   safety sign lights are provided below both sides of the vehicle, and   reflective signs are affixed to the body and rear as standard.

5. All equipment boxes are equipped with LED   lighting to facilitate night combat lighting.

6. There are two strobe lights on each side   of the vehicle, and safety sign lights and side retroreflectors are installed   below.

(Combined type ) , equipped with front and rear side lights, one turn signal   on each side, and lights in the passenger compartment, equipment box, and   pump room .

7. The sirens, warning lights, strobe   lights, and circuits are independent additional circuits, and the control   devices are installed in the cab.

8. All lines are protected by sleeves, and   different colors are used to distinguish the connection forms and functions   of the lines.

9. Equipment on the dashboard in the pump   room: liquid level gauge, tachometer, pressure gauge, vacuum gauge, equipment   box lighting switch, etc.

[ Dashboard and on-board equipment ]

1. The instrument panel is located in the   pump room at the rear of the vehicle, with a control panel and sufficient   lighting;

2. All control handles, switches, and   indicator lights have Chinese logos near them;

3. There are instructions for operating   steps.

4. All signs have durability and high   adhesion, and can withstand the impact of drastic changes in temperature and   climate.

5. The operation panel is made of   high-quality aluminum plate, which is beautiful, durable and light in overall   weight.

6. The operating system of the pump room is   set at the rear of the vehicle, with no pressure outlet to ensure the safety   of the operator, and with panel lighting.
