end    plate

Qingling Isuzu

Dimensions

6100*1960*2660

engine

Isuzu 4KH1CN6LB

power

88KW

Drive type

Rear wheel drive

【 Tank  】

Water tank material

High-quality steel plate with high-tech   anti-corrosion treatment

capacity:

Water: 2000Kg

[ Fire pump and piping system ]

Fire pump model

CB10/20   low pressure fire pump

Installation type

rear

fire pump pressure

 1.0MPa

Fire pump flow

  20L/s

Vacuum pump

Piston type ( wear-resistant,   corrosion-resistant and meets sealing requirements )

Water diversion time

≤35s

Water absorption   depth

≥7m

Maximum vacuum degree

≥85kPa

【 Fire cannon 】

model

PS20 type   fire monitor

pressure

1.0MPa

range

Water ≥ 4 5m

Location

on top of the jug

control

Manual control with locking mechanism for   easy operation

flow

20L / s

【 PTO 】

Type

Full power sandwich power take- off

cooling method

Forced water cooling

[ Equipment box and pump room ]

The frame and skin are made of high-quality carbon   steel; the internal equipment rack is made of aluminum alloy profiles, and   the interior panels are oxidized aluminum plates

【 Electrical system 】

1. The top of the cab is equipped with a long   row of red luxury police lights.

2. The alarm power is 100W;

3. In order to ensure safe use, the entire   vehicle line is made of an integral wiring harness, and waterproof plugs are   used at the connections to ensure line safety during use.

4. The   roof of the vehicle is equipped with a fire scene lighting lamp ; safety sign lights are provided below both   sides of the vehicle, and reflective signs are affixed to the body and   rear as standard.

5. All equipment boxes are equipped with LED   lighting to facilitate night combat lighting.

6. There are two strobe lights on each side   of the vehicle, and safety sign lights and side retroreflectors are installed   below.

(Combined type ) , equipped with front   and rear side lights, one turn signal on each side, and lights in the   passenger compartment, equipment box, and pump room .

7. The sirens, warning lights, strobe lights,   and circuits are independent additional circuits, and the control devices are   installed in the cab.

8. All lines are protected by sleeves, and   different colors are used to distinguish the connection forms and functions   of the lines.

9. Equipment on the dashboard in the pump   room: liquid level gauge, tachometer, pressure gauge, vacuum gauge, equipment   box lighting switch, etc.

[ Dashboard and   on-board equipment ]

1.   The instrument panel is located in the pump room at the rear of the vehicle,   with a control panel and sufficient lighting;

2.   All control handles, switches, and indicator lights have Chinese logos near   them;

3.   There are instructions for operating steps.

4.   All signs have durability and high adhesion, and can withstand the impact of   drastic changes in temperature and climate.

5.   The operation panel is made of high-quality aluminum plate, which is   beautiful, durable and light in overall weight.

6.   The operating system of the pump room is set at the rear of the vehicle, with   no pressure outlet to ensure the safety of the operator, and with panel   lighting.
