end    plate

Sinotruk Howo

ZZ5357TXFV464MF5

Wheelbase

4600+1400mm

engine

Sinotruk MC11.46-61

power

341kW

Drive   type

Rear   wheel drive

【 Tank  】

Water tank material

High-quality   steel plate with high-tech anti-corrosion treatment

Foam   tank:

High   quality 304 stainless steel

capacity:

11900 Kg foam 3824K g

【 Fire pump and piping system】

fire   pump brand

Shanghai   Rongshen

Fire   pump model

CB10/60 low pressure fire pump

fire pump pressure

1.0MPa

Fire pump flow

  60L /s

Installation   type

Rear

Water   diversion time

≤35s

Pump   material

Wear-resistant   and corrosion-resistant to meet sealing requirements

Maximum   vacuum degree

≥85kPa

Water absorption depth

≥7m

Vacuum   pump

Piston   type , vacuum pumps are preferably electric vacuum water diversion pumps of   the same brand as fire pumps.

【 Fire cannon 】

brand

west

model

P L8/48 fire monitor

range

Water ≥ 60 m Foam ≥ 55 m

pressure

1.0MPa

Location

on   top of the jug

【 PTO 】

Type

Full   power sandwich power take- off

cooling   method

Forced   water cooling

【 Equipment box and pump room 】

The frame and   skin are made of high-quality carbon steel; the internal equipment rack is   made of aluminum alloy profiles, and the interior panels are oxidized aluminum plates

【 Electrical system 】

1.   The top of the cab is equipped with a long row of red luxury police lights.

2.   The alarm power is 100W;

3.   In order to ensure safe use, the entire vehicle line is made of an integral   wiring harness, and waterproof plugs are used at the connections to ensure   line safety during use.

4.   The roof of the vehicle is equipped with a   fire scene lighting lamp ; safety   sign lights are provided below both sides of the vehicle, and reflective   signs are affixed to the body and rear as standard.

5.   All equipment boxes are equipped with LED lighting to facilitate night combat   lighting.

6.   There are two strobe lights on each side of the vehicle, and safety sign   lights and side retroreflectors are installed below.

(Combined   type ) , equipped with front and rear side lights, one turn signal on each   side, and lights in the passenger compartment, equipment box, and pump room .

7.   The sirens, warning lights, strobe lights, and circuits are independent   additional circuits, and the control devices are installed in the cab.

8.   All lines are protected by sleeves, and different colors are used to   distinguish the connection forms and functions of the lines.

9.   Equipment on the dashboard in the pump room: liquid level gauge, tachometer,   pressure gauge, vacuum gauge, equipment box lighting switch, etc.

【Dashboard and on-board equipment 】

1.   The instrument panel is located in the pump room at the rear of the vehicle,   with a control panel and sufficient lighting;

2.   All control handles, switches, and indicator lights have Chinese logos near   them;

3.   There are instructions for operating steps.

4.   All signs have durability and high adhesion, and can withstand the impact of   drastic changes in temperature and climate.

5.   The operation panel is made of high-quality aluminum plate, which is   beautiful, durable and light in overall weight.

6.   The operating system of the pump room is set at the rear of the vehicle, with   no pressure outlet to ensure the safety of the operator, and with panel   lighting.
